Sliding gate operator Tousek PULL T24speed
Manufacturer: Tousek
Manufacturer index: 11110550
Index: 2320
High-speed motor for sliding gates weighing up to 400 kg. Designed for residential or industrial applications with a low duty cycle. 24V motor with a gearbox in an oil bath. Equipped with a built-in control unit with a display for easy configuration.
Technical specification
| Maximum gate weight | 400 kg |
|---|---|
| Application | Sliding gates |
| Built-in control unit | ✔ |
| Built-in radio receiver | ✘ |
| Power supply | 230 V AC, 50 Hz |
| Motor power supply | 24 V DC |
| Limit switches | ✘ |
| Synchronous operation of two drives | ✘ |
Efficiency
| Travel speed | 16 m/min |
|---|---|
| Force | 20 Nm |
| Duty cycles | 40–80% (S3 mode) |
| Current consumption | 1 A |
| Power | {brak danych} |
Pinion gear
| Pinion gear module | 4 |
|---|---|
| Height to the top of the pinion gear | 107 mm |
| Interchangeability with others | {brak danych} |
Dimensions, weight
| Protection degree | IP44 |
|---|---|
| Operating temperature | -20 °C ÷ +40 °C |
| Dimensions | 316 × 206.5 × 306.5 mm |
| Weight | {brak danych} |
