Sliding gate operator Sommer RUNner
Manufacturer: Sommer
Manufacturer index: S11566-00002
Index: 2466
Motor for sliding gates weighing up to 600 kg. Designed for residential applications. 24 V motor. Equipped with a built-in control unit and magnetic limit switches.
Technical specification
| Maximum gate weight | 600 kg |
|---|---|
| Application | Residential |
| Built-in control unit | ✔ |
| Built-in radio receiver | ✘ |
| Power supply | 220–240 V AC |
| Motor power supply | 24 V DC |
| Limit switches | Magnetic |
| Synchronous operation of two drives | ✘ |
Efficiency
| Travel speed | 21 cm per second |
|---|---|
| Force | 20 Nm |
| Duty cycles | S3 40% |
| Current consumption | 0.54 A |
| Power | 125 W |
Pinion gear
| Pinion gear module | 4 |
|---|---|
| Height to the top of the pinion gear | 91 mm |
| Interchangeability with others | ✘ |
Dimensions, weight
| Protection degree | IP54 |
|---|---|
| Operating temperature | -30 °C ÷ +50 °C |
| Dimensions | 304 × 169 × 314 mm |
| Weight | 10 kg |
