Sliding gate operator FAAC C721
Manufacturer: FAAC
Manufacturer’s index: 109321
Index: 889
High-speed motor for sliding gates weighing up to 800 kg. Designed for residential applications. 24 V motor. Equipped with a built-in FAAC E721 control unit and magnetic limit switches.
Technical specification
| Maximum gate weight | 800 kg |
|---|---|
| Application | Residential |
| Built-in control unit | ✔ FAAC E721 |
| Built-in radio receiver | ✘ |
| Power supply | 230 V AC |
| Motor power supply | 24 V DC |
| Limit switches | Magnetic |
| Synchronous operation of two drives | ✘ |
Efficiency
| Travel speed | 30 cm per second |
|---|---|
| Force | 530 N |
| Duty cycles | 15 cycles per hour |
| Current consumption | 12 A |
| Power | 290 W |
Pinion gear
| Pinion gear module | 4 |
|---|---|
| Height to the top of the pinion gear | 108 mm |
| Interchangeability with others | ✘ |
Dimensions, weight
| Protection degree | IP44 |
|---|---|
| Operating temperature | -20 °C ÷ +55 °C |
| Dimensions | 300 × 280 × 180 mm |
| Weight | 10 kg |
