Sliding gate operator FAAC C720
Manufacturer: FAAC
Manufacturer’s index: 109320
Index: 563
High-speed motor for sliding gates weighing up to 400 kg. Designed for residential applications. 24 V motor. Equipped with a built-in FAAC E721 control unit and magnetic limit switches.
Technical specification
| Maximum gate weight | 400 kg |
|---|---|
| Application | Residential |
| Built-in control unit | ✔ |
| Built-in radio receiver | ✘ |
| Power supply | 230 V AC |
| Motor power supply | 24 V DC |
| Limit switches | Magnetic |
| Synchronous operation of two drives | ✘ |
Efficiency
| Travel speed | 30 cm per second |
|---|---|
| Force | 320 N |
| Duty cycles | 15 cycles per hour |
| Current consumption | 7 A |
| Power | 170 W |
Pinion gear
| Pinion gear module | 4 |
|---|---|
| Height to the top of the pinion gear | 108 mm |
| Interchangeability with others | ✘ |
Dimensions, weight
| Protection degree | IP44 |
|---|---|
| Operating temperature | -20 °C ÷ +55 °C |
| Dimensions | 300 × 280 × 180 mm |
| Weight | 8 kg |
Manufacturer / Responsible entity
FAAC S.p.A. Soc. Unipersonale
Via Calari 10
40069 Zola Predosa (BO)
Italy
Telephone: +39 051 61724
Via Calari 10
40069 Zola Predosa (BO)
Italy
Telephone: +39 051 61724
